- Fan Size: 120*120*25mm
- Fan Bearing Type: HDB
- Fan Speed: PWM800~2000RPM ±10%
- Fan Noise Level: 31.6dB-A
- Fan Airflow: 65.5CFM (MAX)
- Fan Air Pressure: 2.03mm-H2O (MAX）
- Fan Voltage Rating: DC 12V(Fan)/DC 5V(LED)
- Fan Plug: 4PIN
- Water drain size: L395*W120*H27mm
- Length of water pipe: 380mm
- Pipe Material: EPDM+IIR rubber+ Braided Tubes
- Backplate Material: plastics
- Row Material: aluminium
- Pump Rated Voltage: DC 12V(PUMP)/DC 5V(LED)
- Rated power: ≤4.2W
- Rated speed: 2500PRM±10%
- Noise level: ≤30dB
- Water Pump Plug: 3pin
- Pump Motor Type: 3-phase 6-pole
- Compatible: Intel:1366,2011,115X,1200,1700; AMD:FM1,FM2,FM3,AM2,AM3AM4,AM5"
