描述
220.5 mm
76 mm
150 mm
About 895 g (without packaging)
*Product size, product weight, and related specifications are theoretical values only. Actual measurements between individual products may vary. All specifications are subject to the actual product.
IEEE 802.11b/g/n/ax
2 x 2 MIMO 2.4 GHz
IEEE 802.11a/n/ac/ax
2 x 2 MIMO 5 GHz Low Band
IEEE 802.11a/n/ac/ax
4 x 4 MIMO 5 GHz High Band
2.4 GHz
574 Mbps (theoretical)
5 GHz Low Band
1201 Mbps (theoretical)
5 GHz High Band
4804 Mbps (theoretical)
Total theoretical negotiated rate
6579 Mbps
2.4 GHz & 5 GHz Low Band & 5 GHz High Band (supports prioritize 5 GHz)
Internal antennas
512 MB RAM + 256 MB ROM
*Due to limitations in CPU processing power, memory used by the operating system and pre-installed applications, the actual space available to users may be less than the stated memory capacity. Actual memory space may change due to application updates, user operations, and other related factors.
The drop network cable can be inserted into any one of the four 10/100/1000 Mbps auto-negotiation Ethernet ports to access the Internet.
Power port, Network port, Reset button (pinhole), and H button
Connect to HarmonyOS connect devices or WPS wireless devices with a press of H button
Independent reset pinhole
One "H" indicator (red/blue)
12V DC, 3A
< 36 W
100 – 240V
50 - 60 Hz
802.11kvr protocol, PPPoE/DHCP/static IP address WAN connection methods, Wi-Fi timer, Guest Wi-Fi, Device speed limiting, MAC address filter, Parental control, VPN pass through, DMZ/virtual server
Supports HUAWEI HomeSec™ security protection: Wi-Fi brute force attack prevention, Unauthorized network access prevention, WPA3
Supported
0°C to 40°C (32°F–104°F)
–40℃ to +70℃ (–40℉ to +158℉)
5% to 95% (non-condensing)
