Model Variations |
EV2795-BK: with FlexStand, black EV2795-WT: with FlexStand, white EV2795-FBK: without stand, black EV2795-FWT: without stand, white Note: FlexStand is removable |
Panel |
|
Type |
IPS |
Backlight |
LED |
Size |
27.0" (68.5 cm) |
Native Resolution |
2560 x 1440 (16:9 aspect ratio) |
Viewable Image Size (H x V) |
596.7 x 335.7 mm |
Pixel Pitch |
0.233 x 0.233 mm |
Pixel Density |
109 ppi |
Display Colors |
16.77 million |
Viewing Angles (H / V, typical) |
178° / 178° |
Brightness (typical) |
350 cd/m2
|
Contrast Ratio (typical) |
1000:1 |
Response Time (typical) |
5 ms (gray-to-gray) |
Color Gamut (typical) |
sRGB |
Video Signals |
|
Input Terminals |
USB Type-C (DisplayPort Alt Mode, HDCP 1.3), DisplayPort (HDCP 1.3), HDMI (HDCP 1.4) |
Output Terminals |
USB Type-C (daisy chain) |
Digital Scanning Frequency (H / V) |
USB Type-C: 31 - 89 kHz / 59 - 61 Hz DisplayPort: 31 - 89 kHz / 59 - 61 Hz HDMI: 31 - 89 kHz / 49 - 51 Hz, 59 - 61 Hz |
USB |
|
Upstream |
USB 3.1 Gen 1: Type-B, USB 3.1 Gen 1: Type-C (DisplayPort Alt Mode, Power Delivery Source 70 W max.) |
Downstream |
USB 3.1 Gen 1: Type-A x 3, USB 3.1 Gen 1: Type-C (DisplayPort Alt Mode, Power Delivery Source 15 W max.) |
USB LAN Adapter |
RJ-45 (1000BASE-T) Windows 10 / 8.1 (64-bit, 32-bit), macOS Sierra (10.12) or later |
Audio |
|
Speakers |
1.0 W + 1.0 W |
Input Terminals |
USB Type-C, DisplayPort, HDMI |
Output Terminals |
Headphones (Stereo mini jack) |
Power |
|
Power Input |
AC 100 - 240 V, 50 / 60 Hz |
Typical Power Consumption |
16 W |
Maximum Power Consumption |
164 W |
Power Save Mode |
0.5 W or less |
Features & Functions |
|
Preset Modes |
User1, User2, sRGB, Paper, Movie, DICOM |
Auto EcoView |
Yes |
OSD Languages |
English, German, French, Italian, Japanese, Simplified Chinese, Spanish, Swedish, Traditional Chinese |
Physical Specifications |
|
Dimensions (Landscape, W x H x D) |
611.4 x 368.6 - 545.2 x 230 mm |
Dimensions (Without Stand, W x H x D) |
611.4 x 356.6 x 56 mm |
Net Weight |
8.5 kg |
Net Weight (Without Stand) |
5.7 kg |
Height Adjustment Range |
176.6 mm |
Tilt |
35° Up, 5° Down |
Swivel |
344° |
Pivot |
90° (both clockwise and counter clockwise) |
Hole Spacing (VESA Standard) |
100 x 100 mm |
Environmental Requirements |
|
Operating Temperature |
5 - 35°C |
Operating Humidity (R.H., non condensing) |
20 - 80% |
Certifications & Standards (Please contact EIZO for the latest information.) |
TCO Certified Generation 9, EPEAT 2018 (US), TUV/Ergonomics, TUV/Low blue light content, TUV/Flicker Free, TUV/GS, RCM, CE, UKCA, CB, cTUVus, FCC-B, CAN ICES-3 (B), TUV/S, PSE, VCCI-B, EPA Energy Star, RoHS, WEEE, China RoHS, CCC, China Energy Label Grade1, EAC |
Dedicated Software |
|
Monitor Control Utility Screen InStyle |
Supported |
Supplied Accessories (May vary by country. Please contact EIZO for details.) |
|
Signal Cables |
USB Type-C (2 m) |
Others |
AC power cord (2 m), setup guide |
Warranty |
5 Years Zero bright sub-pixels for six months from date of purchase.
|
Dimension Drawing |
PDF |
