LTRA EFFICIENT
CV series is 80 PLUS Bronze certified, providing up to 88% efficiency for less heat and lower energy costs.
LOW-NOISE OPERATION
A 120mm thermally controlled low-noise cooling fan only spins at high speed when your power supply is under heavy stress, slowing down for quieter operation at lower loads.
COMPACT DESIGN
CV series enclosures are only 125mm long, ensuring an easy fit in almost all modern PC cases.
CV650 POWER TABLE
| MODEL | RPS0128 | |
|---|---|---|
| PART NO. | CP-9020236 | |
| AC Input Rating | ||
| AC INPUT | 100-240V | |
| INPUT CURRENT | 10A-5A | |
| FREQUENCY | 47~63Hz | |
| Max Load | Max Output | |
| +5V | 20A | 130W |
| +3.3V | 24A | |
| +12V | 52A | 624W |
| -12V | 0.3A | 3.6W |
| +5VSB | 3A | 15W |
| TOTAL POWER | 650W | |
