描述
Capacity | 1TB / 2TB / 4TB |
---|---|
Form factor | M.2 2280 |
NAND Flash | 3D NAND |
Controller | SMI SM2264 |
Dimensions (L x W x H) | 80.6 x 23.2 x 10.65mm / 3.17 x 0.91 x 0.42inch(with heat sink) 80 x 22 x 3.3mm / 3.15 x 0.87 x 0.13inch (without heat sink) |
Weight | 36.6g /1.3oz (with heat sink) 7.3g /0.26oz (without heat sink) |
Interface | PCIe Gen4 x4 |
Sequential Read (Max) | Up to 7,400MB/s (PC/Laptop)*, up to 6,400MB/s (PS5) |
Sequential Write (Max) | Up to 6,800MB/s* |
4KB Random Read IOPS(Max) | Up to 750K* |
4KB Random Write IOPS(Max) | Up to 630K* |
Operating temperature | 0°C - 70°C |
Storage temperature | -40°C-85°C |
Shock resistance | 1,500G/0.5ms |
MTBF | 2,000,000 hours |
Terabytes Written (TBW) | 3,120TB** |
Warranty | 5-year limited warranty*** |
